343-2AH10 - Communication processors | Actor/sensor interfaces
Order no. |
343-2AH10 |
| Type | CP 343-2P ASI, AS-i master |
General information |
|
| Note | - |
| Features |
Up to 62 slaves connectable Corresponding to AS-i specification 3.0 (master profile M3) Support of analog slaves concerning profile 7.3 resp. 7.4 Automatic address programming possible (address 0) |
| SPEED-Bus | - |
Current consumption/power loss |
|
| Current consumption from backplane bus | 200 mA |
| Power loss | 2.5 W |
Status information, alarms, diagnostics |
|
| Status display | yes |
| Interrupts | yes |
| Process alarm | - |
| Diagnostic interrupt | yes |
| Diagnostic functions | yes |
| Diagnostics information read-out | possible |
| Supply voltage display | yes |
| Group error display | red SF LED |
| Channel error display | none |
Functionality interfaces |
|
| Type of interface | AS-Interface |
| Connector | 20-pin front connector |
| Electrically isolated | - |
Housing |
|
| Material | PPE |
| Mounting | Rail System 300 |
Mechanical data |
|
| Dimensions (WxHxD) | 40 mm x 125 mm x 120 mm |
| Net weight | 250 g |
| Weight including accessories | - |
| Gross weight | - |
Environmental conditions |
|
| Operating temperature | 0 °C to 60 °C |
| Storage temperature | -25 °C to 70 °C |
Certifications |
|
| UL certification | yes |
| KC certification | - |
CP 343-2P ASI - AS-i master 343-2AH10
