342-2IA71 - Communication processors | Fieldbus master modules
Order no. |
342-2IA71 |
| Type | CP 342S IBS, dual INTERBUS master SPEED-Bus |
General information |
|
| Note | - |
| Features |
Dual INTERBUS master SPEED-Bus 2x RS422 Diagnostic via LEDs Diagnostic device (2x RJ45) Dual Port Master Up to 512 slaves connectable |
| SPEED-Bus | |
Current consumption/power loss |
|
| Current consumption from backplane bus | 1 A |
| Power loss | 4.5 W |
Status information, alarms, diagnostics |
|
| Status display | yes |
| Interrupts | no |
| Process alarm | no |
| Diagnostic interrupt | no |
| Diagnostic functions | no |
| Diagnostics information read-out | none |
| Supply voltage display | yes |
| Group error display | yes |
| Channel error display | none |
Functionality Sub-D interfaces |
|
| Type | X2 |
| Type of interface | RS422 |
| Connector | Sub-D, 9-pin, female |
| Electrically isolated | |
| MPI | - |
| MP²I (MPI/RS232) | - |
| Point-to-point interface | - |
| 5V DC Power supply | max. 90mA isolated and max. 90mA non-isolated |
| 24V DC Power supply | - |
|
|
|
| Type | X3 |
| Type of interface | RS422 |
| Connector | Sub-D, 9-pin, female |
| Electrically isolated | |
| MPI | - |
| MP²I (MPI/RS232) | - |
| Point-to-point interface | - |
| 5V DC Power supply | max. 90mA isolated and max. 90mA non-isolated |
| 24V DC Power supply | - |
Functionality RJ45 interfaces |
|
| Type | DIAG 1 |
| Type of interface | - |
| Connector | RJ45 |
| Electrically isolated | - |
| PG/OP channel | - |
| Number of connections, max. | - |
| Productive connections | - |
| Fieldbus | - |
|
|
|
| Type | DIAG 2 |
| Type of interface | - |
| Connector | RJ45 |
| Electrically isolated | - |
| PG/OP channel | - |
| Number of connections, max. | - |
| Productive connections | - |
| Fieldbus | - |
Housing |
|
| Material | PPE |
| Mounting | DIN rail SPEED-Bus |
Mechanical data |
|
| Dimensions (WxHxD) | 40 mm x 125 mm x 120 mm |
| Net weight | 260 g |
| Weight including accessories | - |
| Gross weight | - |
Environmental conditions |
|
| Operating temperature | 0 °C to 60 °C |
| Storage temperature | -25 °C to 70 °C |
Certifications |
|
| UL certification | - |
| KC certification | - |
CP 342S IBS - INTERBUS master - SPEED-Bus 342-2IA71
