342-1CA70 - Communication processors | Fieldbus master modules
Order no. |
342-1CA70 |
| Type | CP 342S CAN, CANopen master SPEED-Bus |
General information |
|
| Note | - |
| Features |
CANopen master SPEED-Bus 1 Mbit/s 125 CAN slaves connectable 40 Transmit PDOs, 40 Receive PDOs 1 SDO (Server), 127 SDO (Client) Project engineering: VIPA WinCoCT |
| SPEED-Bus | |
Current consumption/power loss |
|
| Current consumption from backplane bus | 550 mA |
| Power loss | 2.75 W |
Status information, alarms, diagnostics |
|
| Status display | yes |
| Interrupts | no |
| Process alarm | no |
| Diagnostic interrupt | no |
| Diagnostic functions | no |
| Diagnostics information read-out | possible |
| Supply voltage display | none |
| Group error display | yes |
| Channel error display | none |
Functionality Sub-D interfaces |
|
| Type | CAN |
| Type of interface | CAN |
| Connector | Sub-D, 9-pin, male |
| Electrically isolated | |
| MPI | - |
| MP²I (MPI/RS232) | - |
| Point-to-point interface | - |
| 5V DC Power supply | - |
| 24V DC Power supply | - |
|
|
|
| Type | - |
| Type of interface | - |
| Connector | - |
| Electrically isolated | - |
| MPI | - |
| MP²I (MPI/RS232) | - |
| Point-to-point interface | - |
| 5V DC Power supply | - |
| 24V DC Power supply | - |
Functionality RJ45 interfaces |
|
| Type | - |
| Type of interface | - |
| Connector | - |
| Electrically isolated | - |
| PG/OP channel | - |
| Number of connections, max. | - |
| Productive connections | - |
| Fieldbus | - |
|
|
|
| Type | - |
| Type of interface | - |
| Connector | - |
| Electrically isolated | - |
| PG/OP channel | - |
| Number of connections, max. | - |
| Productive connections | - |
| Fieldbus | - |
Housing |
|
| Material | PPE |
| Mounting | DIN rail SPEED-Bus |
Mechanical data |
|
| Dimensions (WxHxD) | 40 mm x 125 mm x 120 mm |
| Net weight | 210 g |
| Weight including accessories | - |
| Gross weight | - |
Environmental conditions |
|
| Operating temperature | 0 °C to 60 °C |
| Storage temperature | -25 °C to 70 °C |
Certifications |
|
| UL certification | yes |
| KC certification | - |
CP 342S CAN - CANopen master - SPEED-Bus 342-1CA70
- Brand: Yaskawa
- Product Code: 3421CA70
- Availability: In Stock
-
$0.00
- Ex Tax: $0.00
